Printing method Thermal label mode
Thermal receipt mode (thermal line)
Dot density: 203 dpi 384 dots/line
Printing width: 20mm 58mm (MAX HORIZONTAL: 58mm)
Printing speed: Max 70 mm/sec
CPU memory: 256K / FLASH:8MB
Communication method: Bluetooth
Charging input port: typeC
Print head: thermistor
Power switch: on/off
Paper presence detection: Photoelectric sensor
Graphics: characters, barcodes, QR...
One-dimensional barcode: UPC-A/UPC-E/JAN13 (EAN13)/JAN8 (EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128
QR code: QRCODE/PDF417
Character set: ANK characters
FontA: 1.5x3.0mm
FontB: 1.1x2.1mm
Simple/Traditional: 3.0x3.0mm
Enlarge/rotate characters
You can enlarge 1-8 times both horizontally and vertically, and rotate
and print (0 degree, 90 degree, 180 degree, 270 degree)
Paper type: Thermal paper, self-adhesive paper, etc.
Paper width: 20mm 58mm (max. 58mm)
With paper cutter (not automatic)
Input power supply: 7.4V/2200MAH
Weight: 0.243kg (including lithium battery)
Physical dimensions: 121.59(D) x 89.7(W) x 58.54(H)mm
Working environment Temperature: 0 ~ 45oC, Humidity: 10 ~ 80oC Temperature: -10 60oC, Humidity: 10 90oC
Storage environment: -10 60oC, 93%RH(40oC)
