Brand: TCL

Capacity: 18000BTU

Type: Cooling Only

Control type: Remote

Rated Cooling Capacity (Btu/h): 18000 (3412 ~ 21150)

Rated Cooling Capacity (W): 5100

CSPF (Btu/h.w; W/W): 4.6

Moisture removal (Liters/h): 1.8

Indoor noise level at cooling (dB (A)):

High: 45
Med: 38
Low: 36
Outdoor noise level (dB (A)): 55

Warranty: 1 Year Warranty plus 5 Years Compressor Warranty

Power Supply:

Power Supply: 220-240V~ / 50Hz/1P

Voltage Range: 155~265V

Rated current (Cooling): 7.31 (1.6~12.0) A

Rated input (Cooling): 1700 (300 ~ 2400) W

Max current: 12 A

Max input: 2400 W

Fan System:

Indoor air circulation Cooling (m3/h): 810

Indoor fan type: Cross Flow

Indoor fan speed H/M/L:

Cooling (rpm): 830/780/730/680/620
Dry (rpm): 680
Sleep (rpm): 680
Indoor fan motor output: 25 W

Outdoor fan type: Propeller Fan

Outdoor fan speed: 860rpm

Outdoor fan motor output: 25W

Others:

Refrigerant/Charge (Gram): R32/730

Compressor:

Type: Rotary
Evaporator: 3-bend

Indoor coil:

Number of rows: 2
Tube pitch (a)x row pitch (b): 21 x 12.7mm
Fin spacing: 1.5mm
Fin type (code): Hydrophilic
Tube outside dia.and type: Ø7mm inner groove tube
Coil (length x height x width): 705 x 315 x 25.4mm
Number of circuits: 4
Condenser: double-arranged

Connecting Pipe:

Gas: 1/2''
Liquid: 1/4''
Connecting Wiring (Size x Core number): 4 x 2.5

Dimension & Weight:

Width x Depth x Height

Suitable area: 25-40 m2

Indoor Unit:

Product Dimension: 910 x 206 x 294mm (35.8” x 8.1” x 11.6”)
Packing Dimension: 979 x 292 x 372mm (38.5” x 11.5” x 14.6”) (from packing box)
Net Weight: 9kg
Gross Weight: 12kg
Outdoor Unit:

Product Dimension: 780 x 290 x 605mm (30.7” x 11.4” x 23.8”)
Packing Dimension: 835 x 340 x 628mm (32.9” x 13.4” x 24.7”)
Net Weight: 28kg
Gross Weight: 32kg
